Tecnolab del Lago Maggiore Srl

More labs in this area: EMC testing in Italy · EMC testing in Piedmont

Verbania, Piedmont, Italy

Via dell'Industria 20-22, Fondotoce, Verbania, Piedmont, 28924, Italy

Visit Website Get Quote Claim this listing

About

Tecnolab del Lago Maggiore occupies a building on Via dell'Industria at Fondotoce, a frazione of Verbania on the shore of Lake Maggiore, and holds dual laboratory accreditation - ACCREDIA certificate 00754 in Italy and Perry Johnson Laboratory Accreditation number 89163 in the United States, both to ISO/IEC 17025 - so a single report can be recognised on either side of the Atlantic without re-testing. Its automotive laboratory is the most developed part of the business and publishes a precise standards list rather than a vague claim: CISPR 25 for radio disturbance measurement, ISO 7637-2 for conducted transients on supply lines and ISO 7637-3 for capacitive and inductive coupling on other lines, ISO 10605 for automotive electrostatic discharge, ISO 11452-2 for radiated immunity, and the full ISO 16750 series covering environmental and electrical conditions, electrical loads, mechanical vibration and climatic exposure. Around the EMC work sits the mechanical and climatic qualification an ECU programme actually needs: sinusoidal, random and shock vibration to IEC 60068-2-6, -2-27 and -2-64, cold, dry heat, temperature change, cyclic and steady damp heat and combined cycling to IEC 60068-2-1, -2-2, -2-14, -2-30, -2-38 and -2-78, salt mist to IEC 60068-2-11, IP ingress protection to ISO 20653, and IK impact protection by the vertical hammer method of IEC 62262 and IEC 60068-2-75. Testing is carried out both to the harmonised directives and to individual carmakers' own specifications, with debug and design-rework support when a part fails. Its test data is relied on by certification bodies including DVGW, ETA and the FCC, and it is active in the ANFIA and MESAP automotive and mechatronics clusters. Specialisations are automotive component qualification to OEM specifications, combined EMC with climatic, vibration and ingress protection testing, and dual Italian and US accreditation.

Accreditations

Accreditation
ISO/IEC 17025
EMC Directive 2014/30/EU

Testing Services

Test Type	Applicable Standards
Radiated Emissions	CISPR 25, EN 55025, CISPR 11, EN 55011, CISPR 32, EN 55032, EN 61000-6-4
Conducted Emissions	CISPR 25, EN 55025, CISPR 11, EN 55011, CISPR 32, EN 55032, EN 61000-6-4
Radiated Immunity	ISO 11452-2, IEC 61000-4-3, EN 61000-4-3, EN 61000-6-2
Conducted Immunity	IEC 61000-4-6, EN 61000-4-6, EN 61000-6-2
Conducted Susceptibility	ISO 7637-2, ISO 7637-3, ISO 16750-2
ESD	ISO 10605, IEC 61000-4-2, EN 61000-4-2
EFT/Burst	IEC 61000-4-4, EN 61000-4-4
Surge Immunity	IEC 61000-4-5, EN 61000-4-5
Voltage Dips/Interrupts	IEC 61000-4-11, EN 61000-4-11, ISO 16750-2
Pre-Compliance Testing	CISPR 25, ISO 11452-2, ISO 7637-2, IEC 61000-4-3
Automotive Component EMC	CISPR 25, EN 55025, ISO 11452-2, ISO 7637-2, ISO 7637-3, ISO 10605, ISO 16750-2
Automotive OEM Specifications	CISPR 25, ISO 11452-2, ISO 7637-2, ISO 16750-1, ISO 16750-2, ISO 16750-3, ISO 16750-4
Environmental Testing	ISO 16750-1, ISO 16750-4, ISO 20653, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-11, IEC 60068-2-14, IEC 60068-2-30, IEC 60068-2-38, IEC 60068-2-78, IEC 60529
Mechanical Testing	ISO 16750-3, IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64, IEC 60068-2-75, IEC 62262
Product Safety	IEC 62262, ISO 20653, IEC 60529, EN 60335-1, EN 62368-1

Certifications / Marks

Certification
CE
ACCREDIA 00754
PJLA 89163
DVGW
ETA
FCC

Industries Served

Industry
Automotive
Industrial Equipment
Consumer Electronics
Energy & Power
Household Appliances

Major Equipment

Equipment
EMC test chamber for automotive component testing
EMI receiver
Spectrum analyser
LISN
CDN
Automotive transient generator (ISO 7637-2 / -3)
Automotive ESD simulator (ISO 10605)
RF immunity amplifier and antennas (ISO 11452-2)
Electrical load simulation bench (ISO 16750-2, to 50 A)
Climatic chambers (cold, dry heat, damp heat, temperature change, combined cycling)
Salt mist corrosion chamber (IEC 60068-2-11)
Sinusoidal, random and shock vibration rigs
IP ingress protection test rigs (ISO 20653, IEC 60529)
IK impact test rig - vertical hammer method (IEC 62262, IEC 60068-2-75)
Debug and design-rework support bench
