Avartanam Test Labs LLP

Anand, Gujarat, India

Plot No. 32, Zone-D/4, Phase-1, GIDC Estate, Vallabh Vidyanagar, Anand, Gujarat, 388121, India

Visit Website Get Quote Claim this listing

1 / 2

About

Avartanam Test Labs is a NABL-accredited RF and EMC laboratory in the GIDC industrial estate at Vallabh Vidyanagar near Anand in Gujarat, with over ten years of operating experience. Its distinguishing capability within India's independent laboratory sector is radio measurement depth rather than chamber size: alongside conventional conducted and radiated emission, electrostatic discharge and surge testing, it performs antenna radiation pattern measurement and over-the-air total radiated power and total isotropic sensitivity (TRP and TIS) characterisation from 370 MHz to 6 GHz, plus VSWR and return loss analysis - the measurements that decide whether a wireless product actually performs, as distinct from whether it merely passes emission limits. Accreditation and designation cover NABL to ISO/IEC 17025:2017, Bureau of Indian Standards recognition, and WPC type approval from the Wireless Planning and Coordination wing, so Indian wireless market access can be closed out in-house; the firm is also MSME Udyam registered and DPIIT-recognised under Startup India. Turnaround on RF work is advertised at three to seven days. The engineering offer extends past measurement into RF filter design, custom antenna development, board design review, test jig calibration and consultancy for CE, FCC and BIS certification, and published customer work spans Wi-SUN data concentrator units and network interface cards, electric vehicle chargers with power line communication, and medical devices. Specialisations are wireless and IoT product RF and OTA measurement, WPC and BIS type approval, smart metering and EV charging equipment, and antenna design and tuning.

Accreditations

Accreditation
ISO/IEC 17025
NABL

Testing Services

Test Type	Applicable Standards
Radiated Emissions	CISPR 11, CISPR 32, EN 55032, IEC 61000-6-3, IEC 61000-6-4, IS 6873, FCC Part 15B, FCC Part 15C
Conducted Emissions	CISPR 11, CISPR 32, EN 55032, IEC 61000-6-3, IEC 61000-6-4, EN 50065-1
Radiated Immunity	IEC 61000-4-3, EN 61000-4-3, CISPR 35, IEC 61000-6-1, IEC 61000-6-2
Conducted Immunity	IEC 61000-4-6, EN 61000-4-6, CISPR 35, IEC 61000-6-1, IEC 61000-6-2
ESD	IEC 61000-4-2, EN 61000-4-2
EFT/Burst	IEC 61000-4-4, EN 61000-4-4
Surge Immunity	IEC 61000-4-5, EN 61000-4-5
Harmonics & Flicker	IEC 61000-3-2, EN 61000-3-2, IEC 61000-3-3, EN 61000-3-3
Voltage Dips/Interrupts	IEC 61000-4-11, EN 61000-4-11, IEC 61000-4-29
Power Frequency Magnetic Field	IEC 61000-4-8, EN 61000-4-8
Pre-Compliance Testing	CISPR 32, IEC 61000-4-3, ETSI EN 300 328, FCC Part 15C, IS 6873
Radio Equipment Testing	ETSI EN 300 328, ETSI EN 300 220, ETSI EN 300 330, ETSI EN 301 489-1, ETSI EN 301 489-3, ETSI EN 301 489-17, FCC Part 15.247, FCC Part 15.225, IEEE 802.15.4g (Wi-SUN)
Medical Device EMC	IEC 60601-1-2, EN 60601-1-2
Military EMC	MIL-STD-461F, JSS 55555
Environmental Testing	IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-30, IEC 60068-2-78, IEC 60529
Mechanical Testing	IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-31, IEC 60068-2-32
Product Safety	IEC 62368-1, IEC 61010-1, IEC 61851-1, IS 13252

Certifications / Marks

Certification
WPC
BIS
CE
FCC

Industries Served

Industry
Radio & Wireless
Telecommunications
Medical Devices
Industrial Equipment
Energy & Power
Consumer Electronics
Information Technology

Major Equipment

Equipment
EMC test chamber
Shielded enclosure
Antenna radiation pattern measurement system (370 MHz - 6 GHz)
OTA TRP and TIS measurement system
Vector network analyser for VSWR and return loss
EMI receiver
Spectrum analyser
LISN
CDN
ESD simulator
EFT/burst generator
Surge generator
Harmonics and flicker analyser
RF immunity amplifiers and antennas
Power line communication (PLC) test bench
Environmental and burn-in chambers
Vibration and drop test rigs
IP ingress protection test rigs
RF filter and custom antenna development bench
