RS Schwarze Industrieelektronik GmbH

Schloss Holte-Stukenbrock, North Rhine-Westphalia, Germany

An der Heller 33, Schloss Holte-Stukenbrock, North Rhine-Westphalia, 33758, Germany

Visit Website Get Quote Claim this listing

About

RS Schwarze Industrieelektronik at Schloss Holte-Stukenbrock in eastern North Rhine-Westphalia is an industrial electronics company that runs a DAkkS-accredited EMC laboratory to DIN EN ISO/IEC 17025, under laboratory director Bruno Erdbories. Its principal facility is a Full Anechoic Room measuring 8.2 by 5.2 by 4.2 metres, lined throughout with ferrite absorbers and partially fitted with hybrid pyramidal absorbers, giving a 360-degree absorbing environment with video monitoring of the test item; radiated disturbance field strength is measured from 30 MHz to 6 GHz and radiated immunity generated from 80 MHz to 6 GHz. The chamber is complemented by an open-area free-field measurement site and a shielded test cabin, which together cover conducted disturbance measurement from 9 kHz to 30 MHz and the low-frequency work. The immunity suite is complete to the IEC 61000-4 series: electrostatic discharge, radiated and conducted RF fields, fast transient burst, surge, power frequency magnetic fields, voltage variations and harmonics, with mains harmonic current and flicker measurement on the emission side. Because the company's own business is designing and building industrial electronics, the laboratory is used as much for remediation as for certification: engineers advise on and implement corrective measures - filtering, shielding, grounding and layout changes - when a test fails, rather than simply issuing the report. Specialisations are industrial control and drive electronics, machine and plant electronics, and EMC troubleshooting with in-house redesign capability.

Accreditations

Accreditation
ISO/IEC 17025
DAkkS
EMC Directive 2014/30/EU

Testing Services

Test Type	Applicable Standards
Radiated Emissions	CISPR 11, EN 55011, CISPR 32, EN 55032, CISPR 16-1-4, CISPR 16-2-3, EN 61000-6-3, EN 61000-6-4
Conducted Emissions	CISPR 11, EN 55011, CISPR 32, EN 55032, CISPR 16-1-2, CISPR 16-2-1, EN 61000-6-3, EN 61000-6-4
Radiated Immunity	IEC 61000-4-3, EN 61000-4-3, EN 55035, EN 61000-6-1, EN 61000-6-2
Conducted Immunity	IEC 61000-4-6, EN 61000-4-6, EN 55035, EN 61000-6-1, EN 61000-6-2
ESD	IEC 61000-4-2, EN 61000-4-2
EFT/Burst	IEC 61000-4-4, EN 61000-4-4
Surge Immunity	IEC 61000-4-5, EN 61000-4-5
Harmonics & Flicker	IEC 61000-3-2, EN 61000-3-2, IEC 61000-3-3, EN 61000-3-3, IEC 61000-3-11, IEC 61000-3-12
Voltage Dips/Interrupts	IEC 61000-4-11, EN 61000-4-11, IEC 61000-4-29
Power Frequency Magnetic Field	IEC 61000-4-8, EN 61000-4-8
Pre-Compliance Testing	CISPR 11, CISPR 32, IEC 61000-4-3, EN 61000-6-1, EN 61000-6-2

Certifications / Marks

Certification
CE

Industries Served

Industry
Industrial Equipment
Energy & Power
Consumer Electronics
Information Technology
Automotive
Household Appliances

Major Equipment

Equipment
Full Anechoic Room (FAR) 8.2 x 5.2 x 4.2 m, ferrite and hybrid pyramidal absorbers
Open-area free-field measurement site
Shielded test cabin
Video monitoring of test item
EMI receiver (9 kHz - 6 GHz)
Spectrum analyser
LISN
CDN
ESD simulator
EFT/burst generator
Surge generator
Harmonics and flicker analyser
RF immunity amplifier and antennas (80 MHz - 6 GHz)
Power frequency magnetic field coil
