TDEMI S Series
Description
The Gauss Instruments TDEMI S series is an ultra-high performance real-time spectrum and EMI receiver platform available in eight frequency range configurations from 1 GHz up to 50 GHz, all starting from 1 Hz with the Opt. 1Hz-UG option. Designed as the new benchmark for real-time, communication and EMC testing, it operates as a spectrum analyzer, real-time spectrum analyzer, signal analyzer and — with the EMI-UG option — a fully CISPR/ANSI/MIL-compliant EMI receiver in a single instrument.
The proprietary HyperOverlapping technology delivers oversampling factors up to 1000, providing a significantly improved signal-to-noise ratio and faster real-time updates compared to conventional real-time measurement technology. With 225 MHz real-time analysis bandwidth, 100 dB dynamic range and the ability to extend via external mixers into the Terahertz range, the TDEMI S is suited for demanding applications including 5G certification and beyond. All models are field-upgradeable to higher frequency ranges, and the EMI64k Automation Software Suite supports fully automated measurements in all operating modes. The compact design with 10.1" touchscreen and 12V power input makes it equally suited for lab, field and on-board testing applications.
Product Specifications
Product Details
| Part Number | TDEMI S Series |
| Manufacturer | GAUSS Instruments |
General Parameters
| Frequency Range | 1 Hz to 50 GHz |
| Measurement Type | Both |
| Detectors |
|
| IF Bandwidth (Resolution Bandwidths) |
