SGS Germany GmbH - Puchheim EMC Laboratory

Part of SGS

Puchheim, Bavaria, Germany

Benzstrasse 26, Puchheim, Bavaria, 82178, Germany

Visit Website Get Quote Claim this listing

About

The SGS Germany EMC laboratory at Puchheim west of Munich is one of the largest commercial EMC test estates in southern Germany, operating five semi-anechoic chambers and three shielded EMC chambers. The flagship facility is a 10 metre chamber able to take vehicles up to 12 metres long and 35 tonnes, which puts complete trucks, buses, agricultural tractors and construction machinery inside a full-size absorber hall rather than restricting the site to component work. Emission measurement reaches 40 GHz and radiated immunity fields reach 600 V/m; the power benches handle three-phase harmonics and flicker up to 75 A, surge to 10 kV and 10 kA, ESD to 30 kV, and high-voltage work including ISO/DTS 7637-4 plus surge and burst on DC rails to 1,000 V and 100 A - the combination needed for traction inverters and electric-vehicle powertrains. The regulatory designations are correspondingly broad: DAkkS accreditation to EN ISO/IEC 17025 including ZLG scope for medical devices and in-vitro diagnostics, KBA Technical Service designation for ECE homologation, recognition by the Bundesnetzagentur as a conformity assessment body for US FCC requirements, IECEE CBTL status for CB certification, VCCI registration for Japan and a Korean laboratory listing - so one campaign can be converted into European, North American and East Asian market access. Accredited standards run from the EN 55011 to EN 55035 emission and immunity families and the IEC 61000-4 and 61000-6 series through EN 60601-1-2, ISO 11451 and ISO 11452, RTCA DO-160, MIL-STD-461, FCC Part 15, ETSI EN 301 489 and ITU-T K.20 to K.54, to the vehicle manufacturer specifications of BMW, Volkswagen and Audi, Mercedes-Benz, Renault, Hyundai, Volvo, Scania, Nissan and Fiat Chrysler. Specialisations are automotive and e-mobility, construction and agricultural machinery, medical devices and IVD, rail systems, and marine equipment.

Accreditations

Accreditation
ISO/IEC 17025
DAkkS
FCC Listed
IECEE CB Scheme
VCCI (Japan)
KCC (Korea)
EMC Directive 2014/30/EU
Radio Equipment Directive (RED) 2014/53/EU

Testing Services

Test Type	Applicable Standards
Radiated Emissions	EN 55011, CISPR 11, EN 55012, CISPR 12, EN 55014-1, CISPR 14-1, EN 55015, CISPR 15, EN 55032, CISPR 32, EN 55025, CISPR 25, EN 61000-6-3, EN 61000-6-4, FCC Part 15B, FCC Part 15C, UN-ECE R10
Conducted Emissions	EN 55011, CISPR 11, EN 55014-1, CISPR 14-1, EN 55015, CISPR 15, EN 55032, CISPR 32, EN 55025, CISPR 25, EN 61000-6-3, EN 61000-6-4, FCC Part 15B
Radiated Immunity	EN 61000-4-3, IEC 61000-4-3, EN 55035, EN 55014-2, EN 61000-6-1, EN 61000-6-2, ISO 11452-2, ISO 11451-2, UN-ECE R10
Conducted Immunity	EN 61000-4-6, IEC 61000-4-6, EN 55035, EN 55014-2, EN 61000-6-1, EN 61000-6-2, ISO 11452-4
Radiated Susceptibility	ISO 11452-2, ISO 11452-3, ISO 11452-11, ISO 11451-2, ISO 11451-3, MIL-STD-461G RS103, IEC 61000-4-3
Conducted Susceptibility	ISO 11452-4, ISO 11452-5, ISO 7637-2, ISO 7637-3, ISO 7637-4, MIL-STD-461G CS114, MIL-STD-461G CS115, MIL-STD-461G CS116
ESD	IEC 61000-4-2, EN 61000-4-2, ISO 10605
EFT/Burst	IEC 61000-4-4, EN 61000-4-4
Surge Immunity	IEC 61000-4-5, EN 61000-4-5, ITU-T K.20, ITU-T K.21, ITU-T K.44, IEC 61000-4-18
Harmonics & Flicker	IEC 61000-3-2, EN 61000-3-2, IEC 61000-3-3, EN 61000-3-3, IEC 61000-3-11, IEC 61000-3-12
Voltage Dips/Interrupts	IEC 61000-4-11, EN 61000-4-11, IEC 61000-4-29, IEC 61000-4-34, ISO 16750-2
Power Frequency Magnetic Field	IEC 61000-4-8, EN 61000-4-8, IEC 61000-4-9, ISO 11452-8
Bulk Current Injection (BCI)	ISO 11452-4, MIL-STD-461G CS114
Pre-Compliance Testing	CISPR 25, CISPR 32, IEC 61000-4-3, UN-ECE R10, ETSI EN 301 489-1
Radio Equipment Testing	ETSI EN 301 489-1, ETSI EN 301 489-3, ETSI EN 301 489-17, ETSI EN 301 489-19, ETSI EN 301 489-52, FCC Part 15.247
Medical Device EMC	EN 60601-1-2, IEC 60601-1-2, IEC 61326-2-6, IEC 60601-1-11
Medical Device Regulatory	Regulation (EU) 2017/745 (MDR), Regulation (EU) 2017/746 (IVDR), IEC 60601-1, ISO 13485
Automotive Component EMC	CISPR 25, EN 55025, ISO 11452-1, ISO 11452-2, ISO 11452-4, ISO 11452-5, ISO 11452-8, ISO 11452-9, ISO 11452-11, ISO 7637-2, ISO 7637-3, ISO 7637-4, ISO 10605, ISO 16750-2
Automotive Vehicle-Level EMC	UN-ECE R10, CISPR 12, EN 55012, CISPR 36, ISO 11451-1, ISO 11451-2, ISO 11451-3, ISO 11451-4
Automotive OEM Specifications	BMW GS 95002, Volkswagen / Audi VW 80000, Mercedes-Benz MBN 10284, Renault 36-00-808, Hyundai ES 95400, Volvo STD 515-0003, Scania STD 4278, Nissan 28400NDS02, Fiat Chrysler CS.00054, UN-ECE R10
Railway EMC	EN 50121-1, EN 50121-3-1, EN 50121-3-2, EN 50121-4, EN 50121-5, EN 50155
Military EMC	MIL-STD-461G
MIL-STD-461	MIL-STD-461G
Commercial Aviation EMC	RTCA DO-160G Section 20, RTCA DO-160G Section 21, RTCA DO-160G Section 22, RTCA DO-160G Section 25
Product Safety	EN 62368-1, EN 60335-1, EN 61010-1, EN 60598-1, EN 60601-1

Certifications / Marks

Certification
CE
UKCA
FCC
ISED
VCCI
KC
UN-ECE E-mark
IECEE CB Certificate
SGS Mark

Industries Served

Industry
Automotive
Medical Devices
Industrial Equipment
Information Technology
Multimedia
Household Appliances
Lighting Products
Railway
Aerospace & Defense
Energy & Power
Consumer Electronics
Radio & Wireless
Agricultural & Forestry

Major Equipment

Equipment
Five semi-anechoic chambers
10 m semi-anechoic chamber for vehicles to 12 m / 35 t
Three shielded EMC chambers
Emission measurement to 40 GHz
Radiated immunity field to 600 V/m
Three-phase harmonics and flicker bench to 75 A
Surge generator to 10 kV / 10 kA
ESD simulator to 30 kV
High-voltage DC surge and burst system to 1,000 V / 100 A
ISO 7637-4 high-voltage transient generator
EMI receiver
Spectrum analyser
LISN and artificial networks
CDN
BCI injection probes
RF power amplifiers and immunity antennas
Vehicle dynamometer
Electrical safety and dielectric test benches
